| Place of Origin: | GUANGDONG |
|---|---|
| Brand Name: | Matsuda |
| Certification: | CE,FCC,RHOS |
| Model Number: | ST9600 |
| Minimum Order Quantity: | 1 set |
| Price: | Discuss |
| Packaging Details: | Carton， Package dimensions： 43*21*42CM/SET |
| Delivery Time: | 3-5 Work Days |
| Payment Terms: | Western Union, T/T, L/C, MoneyGram |
| Supply Ability: | 3000 Sets / Month |
| Material: | Aluminum Alloy | Color: | Black, White |
|---|---|---|---|
| CPU: | RK3288 | RAM: | 2G |
| SSD: | 16G/32G | Screen Size: | 15 Inch |
| Resolution: | 1024*768 | Warranty: | 3 Years |
| High Light: | 15.6 Inch Liquor Store Pos System,Touch Screen Liquor Store Pos System,15.6 Inch Waterproof Pos System |
||
Product Parameters
| Part | Setting | Specification | ||
| The host | CPU | RK3288 | J1900/3855 | |
| Cortex-A17 1.8 GHz | Quad core 2.0 GHz/Dual core 1.6 GHz | |||
| OS Support | Android 5.1 | |||
| Display | Display size | 15.6 inch 16:9 | ||
| Resolution | 1920*1080 | |||
| Brightness | 350cd/m2 | |||
| Contrast ratio | 700:1(Typ.)(transmission) | |||
| Touch screen | Pure flat surface capacitance 10 point multi-touch | |||
| Display area | 304.1*228.1mm | |||
| RAM | 2G | |||
| Hard Disk | 16G | |||
| Port | Standard USB | 4*USB 2.0+2*USB 3.0 | ||
| HDMI | 1 | |||
| RS232 | 2*RS232 | |||
| 1*12V DCout | 1 | |||
| VGA | 1 | |||
| Audio | 1 | |||
| Option port | 12V DCout | 1*12V DCout | ||
| COM(RS232) | 1*COM(RS232) | |||
| Peripheral | MSR | LIF-MSR006ISO7811 | ||
| RFID | LIF-RD01 supports mifare one S50,S70 and its compatible TYPE A and B cards | |||
| IC | LIF-PC/SC supports standard HID protocol and PC/SC protocol | |||
| IBUTTON-A | comply with the 1-wire protocol | |||
| Customer dispaly | 12inch 16:10(1280*800) | |||
| VFD | 2*20 LED | |||
| WIFI | 11N wireless 300Mbps | |||
| 4G | Optional | |||
| Speaker | Optional | |||
| Weight | 8.5KG | |||
| Certification | CE,FCC,ROHS | |||
Application
Product Details
Payment
FAQ
1.Q:Are you a manufacturer?
Yes,we are a manufacturer.
2.Q: What warranty do you offer?
Each product with 1 year warranty,expect the human damage and force majeure factor .
Beyond the guarantee period machine ,we will provide maintenance service and technical support.
3.Q:Are you still worry about compatibility of PC with your software?
Before you make the order, you could test your software if compatible with our hardware, you could send your software to us or you could Teamviewer.
4.Q:Do you still have lots of complains of after-sale?
With our experience, it is better for you to have a hardware engineer, Once meet problems,you check and solve it at the first time ,avoid causing other trouble ,even irreversible damage. Also you could return to us ,in order to save the shipping cost ,you’d better collection 3pcs of damaged one,then send back to us together. Shipping cost you pay yourside, we pay ourside.
5.Q: What about minimum order quantity?
We have no limit for MOQ, so you can even buy only 1 piece.
6.Q: Are you factory, can you do OEM/ODM?
Yes, we are factory, we can customize as your requirements.
7.Q:How can I pay for the order?
Our payment terms :T/T ,Western Union ,Paypal,Trade assurance Order.
8.Q:How do I know that you have sent the products out?
Once the products are sent out, a tracking number will be provided so that you can check where your goods at all times.
9.Q:What kind of inspection you can provide ?
Each POS machine will ageing test 48 hours ,to guarantee all POS machine are in the perfect condition before shipment .we also accept the inspection by the third part you appointed.
