Place of Origin: | GUANGDONG |
---|---|
Brand Name: | Matsuda |
Certification: | CE,FCC,RHOS |
Model Number: | ST9500 |
Minimum Order Quantity: | 1 set |
Price: | Discuss |
Packaging Details: | Carton, Package dimensions: 43*21*42CM/SET |
Delivery Time: | 3-5 Work Days |
Payment Terms: | Western Union, T/T, L/C, MoneyGram |
Supply Ability: | 3000 Sets / Month |
Material: | ABS | Color: | Black, White |
---|---|---|---|
CPU: | J1900,I3,I5 | RAM: | 4G,8G |
SSD: | 64G,128G,HDD500G | Screen Size: | 15 Inch |
Resolution: | 1020*1080 | Warranty: | 3 Years |
High Light: | Multifunction Touch Screen Pos System,Windows Touch Screen Pos System,Multifunction 15 Inch Pos System |
Product Parameters
Part | Setting | Specification | ||
The host | CPU | I3-6100U/I5-6360U | J1900/3855 | |
Dual core 2.3 GHz/Dual core 2.0 GHz | Quad core 2.0 GHz/Dual core 1.6 GHz | |||
OS Support | win7 win8 win10 Linux posready 7 above system | |||
Display | Display size | 15 inch | ||
Resolution | 1020(RGB)*1080 | |||
Brightness | 350cd/m2 | |||
Contrast ratio | 700:1(Typ.)(transmission) | |||
Touch screen | Pure flat surface capacitance 10 point multi-touch | |||
Display area | 304.1*228.1mm | |||
RAM | 4G up to 8G | |||
Hard Disk | 64G SSD, Msata, HDD | |||
Port | Standard USB | 4*USB 2.0+2*USB 3.0 | ||
HDMI | 1 | |||
RS232 | 2*RS232 | |||
1*12V DCout | 1 | |||
VGA | 1 | |||
Audio | 1 | |||
Option port | 12V DCout | 1*12V DCout | ||
COM(RS232) | 1*COM(RS232) | |||
Peripheral | MSR | LIF-MSR006ISO7811 | ||
RFID | LIF-RD01 supports mifare one S50,S70 and its compatible TYPE A and B cards | |||
IC | LIF-PC/SC supports standard HID protocol and PC/SC protocol | |||
IBUTTON-A | comply with the 1-wire protocol | |||
Customer dispaly | 12inch 16:10(1280*800) | |||
VFD | 2*20 LED | |||
WIFI | 11N wireless 300Mbps | |||
4G | Optional | |||
Speaker | Optional | |||
Weight | 7.5KG | |||
Certification | CE,FCC,ROHS |
Diversified Applications
FAQ
1.Q:Are you a manufacturer?
Yes,we are a manufacturer.
2.Q: What warranty do you offer?
Each product with 1 year warranty,expect the human damage and force majeure factor .
Beyond the guarantee period machine ,we will provide maintenance service and technical support.
3.Q:Are you still worry about compatibility of PC with your software?
Before you make the order, you could test your software if compatible with our hardware, you could send your software to us or you could Teamviewer.
4.Q: What about minimum order quantity?
We have no limit for MOQ, so you can even buy only 1 piece.
5.Q: Are you factory, can you do OEM/ODM?
Yes, we are factory, we can customize as your requirements.
6.Q:How do I know that you have sent the products out?
Once the products are sent out, a tracking number will be provided so that you can check where your goods at all times.
