Place of Origin: | GUANGDONG |
---|---|
Brand Name: | Matsuda |
Certification: | CE,FCC,RHOS |
Model Number: | ST9500 |
Minimum Order Quantity: | 1 set |
Price: | Discuss |
Packaging Details: | Carton, Package dimensions: 43*21*42CM/SET |
Delivery Time: | 3-5 Work Days |
Payment Terms: | Western Union, T/T, L/C, MoneyGram |
Supply Ability: | 3000 Sets / Month |
Material: | ABS | Color: | Black, White |
---|---|---|---|
CPU: | RK3288 | RAM: | 2G |
SSD: | 16G,32G | Screen Size: | 15.6 Inch |
Resolution: | 1920*1080 | Warranty: | 3 Years |
High Light: | Capacitive Retail Store Pos Systems,Light Pedestal Capacitive Pos Systems,15.6 Inch Retail Store Pos Systems |
Product Parameters
Part |
Setting |
Specification |
||
The host |
CPU |
RK3288 |
J1900/3855 |
|
Dual core 2.3 GHz/Dual core 2.0 GHz |
Quad core 2.0 GHz/Dual core 1.6 GHz |
|||
OS Support |
Android |
|||
Display |
Display size |
15.6 inch 16:9 |
||
Resolution |
1920*1080 |
|||
Brightness |
350cd/m2 |
|||
Contrast ratio |
700:1(Typ.)(transmission) |
|||
Touch screen |
Pure flat surface capacitance 10 point multi-touch |
|||
Display area |
304.1*228.1mm |
|||
RAM |
4G up to 8G |
|||
Hard Disk |
64G SSD, Msata, HDD |
|||
Port |
Standard USB |
4*USB 2.0+2*USB 3.0 |
||
HDMI |
1 |
|||
RS232 |
2*RS232 |
|||
1*12V DCout |
1 |
|||
VGA |
1 |
|||
Audio |
1 |
|||
Option port |
12V DCout |
1*12V DCout |
||
COM(RS232) |
1*COM(RS232) |
|||
Peripheral |
MSR |
LIF-MSR006ISO7811 |
||
RFID |
LIF-RD01 supports mifare one S50,S70 and its compatible TYPE A and B cards |
|||
IC |
LIF-PC/SC supports standard HID protocol and PC/SC protocol |
|||
IBUTTON-A |
comply with the 1-wire protocol |
|||
Customer dispaly |
12inch 16:10(1280*800) |
|||
VFD |
2*20 LED |
|||
WIFI |
11N wireless 300Mbps |
|||
4G |
Optional |
|||
Speaker |
Optional |
|||
Weight |
7.5KG |
|||
Certification |
CE,FCC,ROHS |
Applications
FAQ
1. Do you have the items in stock?
The most of products are in stock. We can send the goods out within 3 days after payment received. For the goods are out of stock, production time is about 7-10 days.
2. Do you offer other relevant items?
Yes we do. We are offering barcode scanner, thermal receipt printer, magnetic card reader, data collector and Pos system.
3. If the goods are damaged badly, who is responsible for it?
We will be responsible for the damaged goods when it is damaged during transport, and we can exchange the new goods for you.
4. How do I know that you have sent the products out?
Once the products are sent out, a tracking number will be provided so that you can check where your goods at all times
5. How will you control product quality?
We strictly control every detail of production, and every product is inspected by our QC team before delivery.
6.Can you send samples for confirmation? Are they free?
Yes, of course, but sample fee is not for free.
7.What about delivery time?
Generally, production needs 7 to 15 days. And it also depends on product and quantity. Samples will be send within 2 days
8. Can customize, modify and develop products according to the design drawing?
Yes, we provide OEM service and can customize products according to the drawing.
9. Whether the price reasonable?
With factory, we promise to provide reasonable and cost-effective price.
10. What about terms of payment?
Payment terms: T/T, west Union and L/C, etc.
11. Can you tell me something about product materials and workmanship?
We adopt environmental protection materials, and they are harmless to human being.
12.Can you list the products of your company?
Epos, touch Pos, receipt printer, cash box and barcode scanner.
13.What about minimum order quantity?
We have no limit for MOQ, so you can even buy only 1 piece.
