| Place of Origin: | GUANGDONG |
|---|---|
| Brand Name: | Matsuda |
| Certification: | CE,FCC,RHOS |
| Model Number: | ST9800 |
| Minimum Order Quantity: | 1 set |
| Price: | Discuss |
| Packaging Details: | Carton， Package dimensions： 43*21*42CM/SET |
| Delivery Time: | 3-5 Work Days |
| Payment Terms: | Western Union, T/T, L/C, MoneyGram |
| Supply Ability: | 3000 Sets / Month |
| Material: | Aluminum Alloy | Color: | Black, White |
|---|---|---|---|
| CPU: | J1900,I3,I5 | RAM: | 4G,8G |
| SSD: | 64G,128G,HDD500G | Screen Size: | 15 Inch |
| Resolution: | 1024*768 | Warranty: | 3 Years |
| Highlight: | Capacitive Retail POS System,Capacitive Retail POS,Retail POS System Capacitive |
||
Product Parameters
| Part | Setting | Specification | ||
| The host | CPU | I3-6100U/I5-6360U | J1900/3855 | |
| Dual core 2.3 GHz/Dual core 2.0 GHz | Quad core 2.0 GHz/Dual core 1.6 GHz | |||
| OS Support | win7 win8 win10 Linux posready 7 above system | |||
| Display | Display size | 15 inch 4:3 | ||
| Resolution | 1024(RGB)*768 | |||
| Brightness | 350cd/m2 | |||
| Contrast ratio | 700:1(Typ.)(transmission) | |||
| Touch screen | Pure flat surface capacitance 10 point multi-touch | |||
| Display area | 304.1*228.1mm | |||
| RAM | 4G up to 8G | |||
| Hard Disk | 64G SSD, Msata, HDD | |||
| Port | Standard USB | 4*USB 2.0+2*USB 3.0 | ||
| HDMI | 1 | |||
| RS232 | 2*RS232 | |||
| 1*12V DCout | 1 | |||
| VGA | 1 | |||
| Audio | 1 | |||
| Option port | 12V DCout | 1*12V DCout | ||
| COM(RS232) | 1*COM(RS232) | |||
| Peripheral | MSR | LIF-MSR006ISO7811 | ||
| RFID | LIF-RD01 supports mifare one S50,S70 and its compatible TYPE A and B cards | |||
| IC | LIF-PC/SC supports standard HID protocol and PC/SC protocol | |||
| IBUTTON-A | comply with the 1-wire protocol | |||
| Customer dispaly | 12inch 16:10(1280*800) | |||
| VFD | 2*20 LED | |||
| WIFI | 11N wireless 300Mbps | |||
| 4G | Optional | |||
| Speaker | Optional | |||
| Weight | 7.5KG | |||
| Certification | CE,FCC,ROHS | |||
Application Field
FAQ
1.Q:Are you a manufacturer?
Yes,we are a manufacturer.
2.Q: What warranty do you offer?
Each product with 1 year warranty,expect the human damage and force majeure factor .
Beyond the guarantee period machine ,we will provide maintenance service and technical support.
3.Q:Are you still worry about compatibility of PC with your software?
Before you make the order, you could test your software if compatible with our hardware, you could send your software to us or you could Teamviewer.
4.Q:Do you still have lots of complains of after-sale?
With our experience, it is better for you to have a hardware engineer, Once meet problems,you check and solve it at the first time ,avoid causing other trouble ,even irreversible damage. Also you could return to us ,in order to save the shipping cost ,you’d better collection 3pcs of damaged one,then send back to us together. Shipping cost you pay yourside, we pay ourside.
5.Q:I haven't done business with you guys before,how can i trust your company?
A:Our company has been in Alibaba.com for 7 years,which is longer than most of our fellow suppliers,we've been golden suppliers for years.what'smore,we've got quite a lot authority certificates,for example,CE, RoHS, ISO9001, BV, Alibaba onsite check certificate. I hope those above will be persuasive enough.
6.Q: Are you factory, can you do OEM/ODM?
Yes, we are factory, we can customize as your requirements.
